380V Automatic Plastic Strapping Production Line 5mm PP Strapping Tape Extrusion Machine

Automatic PP plastic strapping production line 5mm strapping tape extrusion production line Servo winding machine

Description of pp strap band extrusion line:

pp strap extrusion machine​

Raw materials-----pp strap extrusion machine​ can produce plastic raw materials: recycled materials or PP polypropylene new materials to produce strapping tape;

Screw-----The equipment adopts high-precision high-quality screws, adopts well-known brands, and has unique parameter design. It has the advantages of large extrusion volume, good plasticization, high hardness and wear resistance; equipped with a quantitative extrusion system, the width and thickness of the produced belts are the same, the error range is small, and it meets the national strapping tape acceptance standards;

 Automatic screen changer------Equipped with a non-stop automatic screen changer, the screen does not need to be stopped, and the efficiency is maximized. 4-net circulation large-area filtration does not require frequent screen changes.

Working principle of PP polypropylene extruder:

The feeding section ------- feeds the PP polypropylene pellets through the hopper into the extruder.

Extrusion ------- screw is heated and rotated to melt and extrude the material.

Extrusion ------ extrudes the melted polypropylene strip blanks through the die to form the desired shape.

Cooling & Shaping ------ The extruded product is shaped and cooled by cooling water tank device.

Stretching ------- stretching oven heats the PP strip blanks and stretches them, ratio 1-10 times.

Shaping-------Shaping oven will heat and shape the PP tape again to make the finished product specification more standard.

Winding -------- will wind the finished PP belt into rolls and put it into storage.

                                             EXTRUSION PARAMETERS TABLE

Working process of PP strapping equipment:

1. PLC control------

      Adopting PLC control system, unique built-in memory parameters, the same product does not need to be debugged multiple times.

2.Embossing wheel-------

                              the upper and lower patterns are consistent, the thin stripes are clear, high-end quality, SKD-11 material, wear-resistant and durable.

Applicable to balers:

1. Fully automatic baler

2. High-speed baler

3. Semi-automatic baler

4. Handheld electric baler

5. Manual clamp baler

FAQ:

Q:What is the voltage of pp strapping band making machine?
A:380V/50HZ, we support customization
Q:Can the pp strapping band making machine be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the pp strapping band making machine?
A:We are from China.
Q:Can pp strapping band making machine provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of pp strapping band making machine?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does pp strapping band making machine customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
