9-25mm PET Plastic Steel Belt Production Line Pollution Free Automatic Winding
Product Details
| Name: | PET Plastic Steel Belt Machinery | Strap Width: | 9-32 Mm |
|---|---|---|---|
| Strap Thickness: | 0.6-1.2 Mm | Paper Tube Size: | Ø406*180 Mm |
| Metering Melt Pump: | 100 CC | Screen Changer: | Chemical Fiber Filter |
| Control Mode: | PLC | Extrusion Method: | High Speed |
| Not Easy To Break: | YES | Wrapping Machine: | Automatic/semi-automatic |
| Line Speed: | 100-200 M/min | Automation: | Automation PET |
| Highlight |
25mm Plastic Steel Belt Production Line,Pollution Free PET Steel Belt Production Line |
||
Product Description
PET plastic steel belt machinery 9-25mm PET plastic steel belt production line PET sheet extruder
FEATURE DESCRIPTION OF PET PLASTIC STEEL BELT MACHINERY
PET plastic steel belt machinery
PET plastic steel belt machinery (equipment used to produce or use PET plastic strapping) has the following characteristics:
Energy-saving and environmentally friendly
Constant temperature process: PET material has a low melting point (approximately 250-260°C), resulting in lower energy consumption compared to traditional steel belt production.
Pollution-free: The production process produces no toxic gases, meeting environmental standards (PET is recyclable).
Waste recycling: Recycled PET shreds can be used directly in production, reducing raw material waste and saving costs.
PET strapping production line process flow
① Loading →② Mixing raw materials →③ Pre-drying raw materials →④ Vacuum dehumidification of raw materials →⑤ Melting and metering extrusion of raw materials →⑥ Cooling and forming of raw materials (strips) →⑦ Preheating in the oven →⑧ Primary stretching →⑨ Secondary stretching →⑩ Embossing →⑪ Oven tempering and shaping →⑫ Cooling →⑬ Finished product winding
EXTRUSION PARAMETERS TABLE
| Model | PET-2 | PET-3 | PET-4 | PET-6 | PET-8 |
| Raw materials | 100% Bottle flakes/crushed materials | ||||
| Number of tapes | 2 | 3 | 4 | 6 | 8 |
| Width (mm) | 9-32 | ||||
| Width (mm) | 0.4-1.2 | ||||
| Maximum line speed(m/min) | ≧150 | ≧150 | ≧150 | ≧150 | ≧150 |
| PLC control system | PLC | PLC | PLC | PLC | PLC |
| Screw Model | 90 | 100 | 125 | 150 | 180 |
| Reducer model | 200 | 250 | 280 | 315 | 350 |
| Dryer tank | 3000L | 4000L | 5000L | 6000L | 6000L |
| Dehumidifier | 1000 | 1000 | 2000 | 3000 | 3500 |
| Metering Pumps | 100CC | 100CC | 100CC | 100CC | 100CC |
| Screen Changer | Single cylinder | ||||
| Winding machine | Automatic winding/ Semi-automatic winding | ||||
| Production capacity /24 H | 5-6T | 7-8T | 10-12T | 12-15T | 18-20T |
Extrusion scre-------
The extruder of the PET plastic steel belt machinery adopts a PET special screw with a unique parameter design. The screw has a unique separation and mixing effect, which ensures the uniform plasticization of the raw materials. It has the advantages of large extrusion volume, good plasticization, high hardness, and high wear resistance.
Advantages of PET plastic steel straps:
Environmental protection-----PET material can be recycled and regenerated, in line with environmental regulations. And there are no sharp edges after packaging, avoiding scratches on goods or people, and meeting logistics safety standards.
Easy to operate------Good flexibility, easy and safe operation, no sharp edges of steel straps, will not scratch the packaging, even if it is tied tightly, it will not hurt people when cut open
After-sales service
PET plastic steel belt machinery provides comprehensive technical support and services. We have an experienced technical team that can quickly provide a variety of services, including:
Pre-sales:
1. Layout of PET plastic steel belt machinery.
2. Analysis of finished product manufacturing costs of PET plastic steel belt machinery.
3. Analysis of raw materials used in PET plastic steel belt machinery.
After-sales service:
1. Waterway diagram, circuit diagram, pipeline connection drawings, etc. of PET plastic steel belt machinery .
2. Installation, commissioning and training of PET plastic steel belt machinery .
3. Maintenance service of PET plastic steel belt machinery .
4. Regular maintenance and repair
5. Fault diagnosis
6. Software update and upgrade
7. Spare parts and accessories
8. Training and technical consultation
FAQ:
Q: What is the voltage of the PET plastic steel belt machinery ?
A: 380V/50HZ, three-phase (customization supported)
Q: What is the extrusion capacity of the PET plastic steel belt machinery ?
A: Different models have different extrusion capacities, with capacities ranging from 150-600KG/H
Q: What is the producible width of the PET plastic steel belt machinery?
A: 9-32mm
Q: Can the PET plastic steel belt machinery be customized?
A: Customization supported
Q: Where does the PET plastic steel belt machinery come from?
A: China.
Q: What are the certifications for the PET plastic steel belt machinery ?
A: ISO CEO certification.
Q: What is the minimum order quantity for the PET plastic steel belt machinery ?
A: 1 set
Q: What is the weight of the PET plastic steel belt machinery ?
20T, 40GP container * 3PCS
