PP strap making machine 5-18mm single-screw pp strapping band making machine with PLC control
DESCRIPTION OF PP STRAPPING BELT EQUIPMENT:
PP strapping belt equipment /PP strap making machine
PP strapping belt, also known as polypropylene strapping belt, is a strapping tape made of polypropylene brushed resin as the main raw material. It has superior characteristics:
Good plasticity-----can be formed into various shapes and sizes as needed, width: 5-19mm, thickness: 0.3-1.2mm.
Strong breaking tensile force----has a high load-bearing capacity, suitable for various occasions that require packaging and fixing.
Bending resistance----will not easily break or damage even after multiple bending.
Low density----relatively light weight, easy to carry and use.
PP strapping belt is also very easy to use, so it is widely used in many fields, including but not limited to logistics, packaging, transportation, electronic products, hardware, home appliances, clothing, etc.
EXTRUSION PARAMETERS TABEL
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Drying barrel (kg) |
100 |
150 |
200 |
200 |
200 |
200 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
Feeding and Plasticizing Extrusion:
Polypropylene granules (virgin or recycled) and the necessary masterbatch are fed into the extruder through a hopper.
In the extruder, the material is heated (electrically) and melted by the shearing action of the screw, forming a uniform, viscous fluid.
The molten PP material, propelled by the screw, passes through a specially designed "die" (die head) and is extruded into one or more continuous, thin strips.
ABOUT AFTER-SALES
We provide comprehensive technical support and service for our PP Strap Making Machine. Our team of experienced technicians can provide a variety of services, including:
Pre-sales:
1.Layout plan of PP strap making machine.
2.Analysis of the cost of PP strap making machine.
3.Raw materials that can be used for PP strap making machine.
After-sales service:
1.Water and electricity circuits of PP strap making machine, circuit drawings, etc.
2.Installation, commissioning and training of PP strap making machine.
3.Maintenance service of PP strap making machine.
4.Regular maintenance and repair
5.Troubleshooting and diagnosis
6.Software updates and upgrades
7.Spare parts and accessories
8.Training and technical advice
FAQ:
Q:What is the voltage of PP strap making machine ?
A:380V/50HZ, we support customization
Q:What is the length of the PP strapping belt?
A: L:36 M.
Q:Where is the PP strap making machine?
A:We are from China.
Q:Can PP strap making machine provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strap making machine?
A:We have 30 years of manufacturing experience, and have their own PP strap making machine plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strap making machine customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
Q:What does the wrapping machine part of the PP strapping belt equipment look like?
A:Equipped with automatic wrapping machine/semi-automatic wrapping machine.
