Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine

I'm Online Chat Now

Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine

Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine
Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine

Large Image :  Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine

Product Details:
Place of Origin: CHINA
Brand Name: HL
Certification: CE
Model Number: HL-101
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiable
Packaging Details: Wooden box or carton
Delivery Time: 5-10 days
Payment Terms: L/C, T/T
Supply Ability: 200 set/Monthly
Contact Now Chat Now

Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine

Description
Name: Automatic Strapping Machine High Efficiency And Energy Saving: YES
Bonding Method: H Ot Melt Bonding Bundling Speed: 1.5 Seconds/strip
Automatic Packaging: YES Belt Width:: 5-15mm
Belt Thickness: 0.4-1.2mm Arrow Size: 800*600 (customizable)
Control System: PLC Control Power Supply: 220 V/60 HZ 380 V/50 HZ
Power Consumption: 0.72 Kw Packaging Material: Plastic, PP
Automatic Grade: Automatic Application: Beverage
Highlight:

Automatic Continuous PP Strapping Machine

,

1.8 Seconds/Track Auto Strapping Machine

,

1.8 Seconds/Track Carton Strapping Machine

Continuous PP strapping automatic strapping machine High-speed packaging machine Desktop strapping machine



PRODUCT DESCRIPTION OF AUTOMATIC STRAPPING MACHINE



Automatic strapping machine



a: Automatic strapping machine, without manual belt insertion, high working efficiency, one full automatic strapping machine is equivalent to 5 semi-automatic strapping machines.

b. There are four packing methods for this machine, manual, pedal, automatic and continuous.

c. The parts of the movement are precisely processed by computer numerically controlled machine tools, and the matching accuracy reaches the micron level.

d. The key machine parts are made of high-strength, corrosion-resistant materials and have a long service life.
e. Packing noise is low, and it stops immediately after packing technology, which saves electricity and is practical.
f. The standard frame of this machine is 800*600 mm. If the size of your goods is larger or smaller than this size, we can also customize it according to your size.



WORKING PRICIPLE

Take the special strapping machine for light strapping as an example. Put the strapping object on the table, adjust the strapping length, and the machine will automatically supply the strapping. The operator will wrap the strapping around the object, insert the strapping head and touch the micro switch. The machine will complete the actions of strapping, tensioning, cutting, hot melting, pressing, etc. in sequence to complete the single strapping process.



Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine 0







                                             PARAMETERS



Name Automatic strapping machine
Bundling speed ≤1.8seconds/track
Work surface height 750mm
Panel load-bearing capacity 60KG
Binding force 0-60KG(Adjustable)
Frame size W800*H600mm (Customizable)
Bundling method inching, foot switch, continuous beating, etc
Strap Width 5-15mm
Weight 150KG
Power supply 220V 50/60HZ.1P
Color white red (customizable)
Machine Size L1150*W650*H1500mm
Wooden box size L1300*W700*H1600mm





DETAILS



Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine 1

Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine 2

Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine 3



Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine 4

Suitable for finished PP straps



Automatic Continuous PP Strapping Machine 1.8 Seconds/Track Carton Strapping Machine 5

FAQ:

Q: Can we place a small order?
A: Yes, we can accept small orders
Q: How long is the delivery time?
A: We will complete the delivery within 3- 10 days after you place the order
Q: Can I get some samples to test before placing an order?
A: Yes, if you are willing to pay the courier fee, we can provide some samples for free for your inspection.
Q: Can you accept us to visit your factory?
A: Welcome to visit our company
Q: Can you make other sizes and packages for this product?
A: Yes, we can produce other sizes according to your requirements, usually our quotation includes ordinary packaging.
If you need your own package, you'd better let us know your requirements in advance so as to get an accurate quotation
