PLC PP Strap Making Machine Plastic Strapping Production Line Intelligent Operation
Product Details
| Motor Power: | 45 KW | Name: | PP Strapping Belt Equipment |
|---|---|---|---|
| Plastic Extruder: | PP | Width: | 5-19 Mm |
| Thickness: | 0.3-1.2 Mm | Production Capacity: | 110-600 Kg/ H |
| Control Mode: | PLC | Material: | PP |
| Environmental Protection: | YES | Automatic Winding Machine: | YES |
| Screen Changer: | Automatic Screen Changer | Metering Pump: | 50 CC |
| Highlight |
PLC PP Strap Making Machine,Intelligent Operation PP Strap Making Machine |
||
Product Description
PP strapping plastic machinery PP strapping production line High-speed strapping machine
Product Description of PP strapping production equipment:
PP strapping belt equipment
Raw materials-----100% polypropylene new material or recycled material, or a combination of
Auxiliary materials------ calcium carbonate and other materials can be added to reduce costs, and dyeing masterbatch can be added to change the color.
Line speed------The finished product line speed can reach 200-300 m/min, high speed, intelligent operation.
Winding machine------PP strapping equipment can be equipped with a fully automatic winding machine or a semi-automatic winding machine (customers should choose according to their own requirements)
EXTRUSION PARAMETERS TABEL
| Model | PP-2 | PP-4 | PP-6 | PP-8 | PP-10 | PP-12 |
| Raw material | PP polypropylene new material/recycled material | |||||
| Number of tapes | 2 | 4 | 6 | 8 | 10 | 12 |
| Width(mm) | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 |
| Thickness(mm) | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 |
| Line speed(m/min) | ≧260-300 | |||||
| PLC control system | PLC | PLC | PLC | PLC | PLC | PLC |
| Screw Model | 90 | 110 | 125 | 135 | 135 | 135 |
| Reducer model | 200 | 220 | 250 | 280 | 280 | 280 |
| Drying barrel (kg) | 100 | 150 | 200 | 200 | 200 | 200 |
| Winding machine | Automatic winding machine /Semi-automatic winding machine | |||||
| Screen Changer | Automatic/Manua | |||||
| Production capacity 24H | 2.5-3T | 6-7T | 8-9T | 10-11T | 12-13T | 13--14T |
Main components
The PP strapping production line is mainly composed of the following parts:
Feeder--- transfers PP polypropylene raw materials to the machine barrel.
Extruder--- used for melting and extrusion of plastics.
Die head--- controls the molding of the extruded plastic strip.
Cooling water tank--- cools the extruded plastic strip.
Stretching oven--- ensures the stretching ratio of the strip and more uniform plastic molding.
Tractor: stretches the formed plastic.
Forming oven--- further ensures the stability of the shape of the plastic.
Winding machine---- winds the formed plastic strapping tape into rolls and puts it into storage.
PLC control system---- controls the entire machine, specification debugging, and parameter ratio setting.
PP strapping tape is suitable for baling machines:
Fully automatic strapping machine
Semi-automatic strapping machine
High-speed ultra-thin strapping machine
Handheld electric strapping machine
Manual strapping machine (iron buckle)
FAQ:
Q:What is the voltage of PP strapping belt equipment ?
A:380V/50HZ, we support customization
Q:What is the length of the PP strapping belt?
A: L:36 M.
Q:Where is the PP strapping belt equipment?
A:We are from China.
Q:Can PP strapping belt equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping belt equipment?
A:We have 30 years of manufacturing experience, and have their own PP strapping belt equipment plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping belt equipment customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
Q:What does the wrapping machine part of the PP strapping belt equipment look like?
A:Equipped with automatic wrapping machine/semi-automatic wrapping machine.
