4-straps PP strapping production line 110*3300mm PP strapping equipment automatic strapping machine
PRODUCT DESCRIPTION OF PP STRAPPING BAND MAKING MACHINE
PP strapping band making machine
The main components of PP strapping band making machine:
PP strapping band making machine is a high-speed extruder that can produce PP strapping band for strapping various products.
It has the following features:
1. High-speed extrusion---- It uses a high-efficiency extruder, quantitative extrusion, high production capacity, to ensure fast and continuous production, 24-hour power outages, and can produce 2-12 PP tapes at the same time.
2. Automatic control---- PLC automatic system control, easy debugging, reduce manual intervention, and improve production efficiency.
EXTRUSION PARAMETERS TABLE
| Model |
PP-2 |
PP-4 |
PP-6 |
PP-8 |
PP-10 |
PP-12 |
| Raw material |
PP polypropylene new material/recycled material |
| Number of tapes |
2 |
4 |
6 |
8 |
10 |
12 |
| Width(mm) |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
5-19 |
| Thickness(mm) |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
0.4-1.2 |
| Line speed(m/min) |
≧260-300 |
| PLC control system |
PLC |
PLC |
PLC |
PLC |
PLC |
PLC |
| Screw Model |
90 |
110 |
125 |
135 |
135 |
135 |
| Reducer model |
200 |
220 |
250 |
280 |
280 |
280 |
| Winding machine |
Automatic winding machine /Semi-automatic winding machine |
| Screen Changer |
Automatic/Manua |
| Production capacity 24H |
2.5-3T |
6-7T |
8-9T |
10-11T |
12-13T |
13--14T |
Screw-----
The extruder screw can be twin-screw or single-screw extrusion, and can produce all-plastic PP belts or sandwich PP belts.
The machine model can be customized according to customer requirements.
Applicable to balers:
1. Fully automatic baler
2. High-speed baler
3. Semi-automatic baler
4. Handheld electric baler
5. Manual clamp baler
FAQ:
Q:What is the voltage of PP strapping band making machine?
A:380V/50HZ, we support customization
Q:Can the PP strapping band making machine be customized according to the factory length?
A:Yes, we can customize the length according to the customer's factory size.
Q:Where is the PP strapping band making machine?
A:We are from China.
Q:Can PP strapping equipment provide after-sales service?
A:Yes, we have professional after-sales engineers who provide 24-hour online guidance.
Q:Is the quality of PP strapping equipment stable?
A:We have 30 years of manufacturing experience, and have their own PP packaging belt production plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping equipment support customization?
A:We are a manufacturing plant that can customize model size, extrusion capacity, voltage and so on according to customer requirements.
