Handheld electric strapping machine electric strapping machine PP PET strap strapping machine
DESCRIPTI OF PP PET HANDHELD ELECTRIC STRAPPING MACHINE
Handheld electric strapping machine
Handheld electric strapping machine is a portable and efficient industrial strapping tool. Powered by electricity, it automatically performs the processes of tightening, sealing (or locking), and cutting the strapping band, thus replacing traditional manual or semi-automatic strapping tools.
This handheld electric strapping machine features intelligent adjustment, adapting to various strapping tape specifications and supporting multiple materials such as PP and PET plastic steel straps. It has a wide range of compatible strap widths (typically 9–19mm) and can precisely adjust the strapping force based on the weight of the goods. This allows it to securely fasten large, heavy items (such as building materials and appliances) while also preventing damage to fragile or easily deformed goods like cardboard boxes and fruit and vegetable crates.
Handheld Electric Strapping Machine
Electric Strapping Machine
Automatic Strapping Machine
PP PET Strapping Machine
Electric Strapping Tool
MACHINE PARAMETERS
| Name |
Handheld Electric Strapping Machine |
| Strapping Type |
PP PET belt |
| Strapping belt width |
11-19mm |
| Strapping belt thickness |
0.4-1.2mm |
| Tightening force |
0-3200N(Adjustable) |
| Interface type |
Friction hot melt bonding |
| Battery capacity |
40.A/h 50/60hz 75w |
| Suitable voltage |
100-230V |
| Machine size |
380*130*130mm |
| Charging time |
90 min |
| Machine weight |
4.0kg |
| Carton size |
400*140*150mm |
1. Core Structure
Power System: Built-in rechargeable lithium battery (common voltages are 12V, 18V, etc.) provides power to the motor, supporting cordless operation. Battery life varies depending on the model, supporting hundreds to thousands of strapping cycles.
Tightening Mechanism----- Driven by a motor via gears or belts, the clamping mechanism grips the strapping band (such as PP or PET strapping) for quick tightening. The tightening force is adjustable (usually ranging from 50-3000N).
Sealing/Joining Mechanism----- Depending on the type of strapping band, there are two methods:
Heat Sealing-----The plastic strapping band is melted and pressed together using a heating element, suitable for PP and PET strapping.
Mechanical Joining----- The strapping band is mechanically joined and secured using metal teeth, suitable for high-strength PET steel strapping or PP strapping.
.
Key Features and Advantages
High Efficiency
Pneumatic strapping machines operate at exceptional speeds, typically completing a full cycle of tensioning, bonding, and cutting within 1-2 seconds. This significantly enhances production efficiency in assembly line operations and bulk packaging.
High Strapping Force and Robustness
Utilising pneumatic motors and cylinders, it generates substantial and consistent tension force, far exceeding manual tightening strength. The heat-sealed joint achieves 50%-80% of the strap's tensile strength, delivering exceptional reliability—particularly suited for heavy goods requiring high-strength securing.
FAQ:
Q: How many batteries does the handheld electric baler have?
A: Normally 1, 2-3 can be selected according to demand
Q; Is the handheld electric baler suitable for PP PET strapping belt?
A: The same machine can be used for 2 types of PP PET strapping belts, and the spring needs to be replaced. The tightening force is different, and the selected spring is also different.
Q: Is the handheld electric baler suitable for air transportation?
A: Yes, we have test data
Q: Does the handheld electric baler have a warranty?
A: Warranty time: 12 months
Q: Where is the handheld electric baler made?
A: China, FE/CO certificate of origin can be provided
Q: What are the specifications suitable for the handheld electric baler?
A: PP PET Strapping belt width: 11-19mm
Q: MOQ?
A: 1 PCS
