Fully automatic strapping machine 5-15mm automatic strapping machine high-speed packaging machine
Product Details
| Name: | Automatic Strapping Machine | High Efficiency And Energy Saving: | YES |
|---|---|---|---|
| Bonding Method: | H Ot Melt Bonding | Bundling Speed: | 1.5 Seconds/strip |
| Automatic Packaging: | YES | Belt Width:: | 5-15mm |
| Belt Thickness: | 0.4-1.2mm | Arrow Size: | 800*600 (customizable) |
| Control System: | PLC Control | Power Supply: | 220 V/60 HZ 380 V/50 HZ |
| Power Consumption: | 0.72 Kw | Packaging Material: | Plastic, PP |
| Automatic Grade: | Automatic | Application: | Beverage |
| Highlight |
fully automatic strapping machine 5-15mm,high-speed automatic strapping machine,automatic packaging machine with warranty |
||
Product Description
Fully automatic strapping machine 5-15mm automatic strapping machine high-speed packaging machine
Description of Automatic Strapping Machine:
Automatic strapping machine
Automatic strapping machine is an automated device used for packaging and bundling products. It has a fast bundling speed and is used for PP plastic tape. It is widely used in logistics, warehousing, manufacturing and other industries. It can automatically complete operations such as bundling and packaging of items, improve efficiency and reduce labor costs. The main functions of the automatic .
Highly automated and intelligent
One-button operation: continuous strapping/foot pedal/inching (3 operating modes available). The operator simply presses the start button or triggers the machine via a foot switch, and the machine automatically completes a series of actions including strap feeding, tensioning, heat sealing, and cutting.
PARAMETERS
| Name | Automatic strapping machine |
| Bundling speed | ≤1.8seconds/track |
| Work surface height | 750mm |
| Panel load-bearing capacity | 60KG |
| Binding force | 0-60KG(Adjustable) |
| Frame size | W800*H600mm (Customizable) |
| Bundling method | inching, foot switch, continuous beating, etc |
| Strap Width | 5-15mm |
| Weight | 150KG |
| Power supply | 220V 50/60HZ.1P |
| Color | white red (customizable) |
| Machine Size | L1150*W650*H1500mm |
| Wooden box size | L1300*W700*H1600mm |
Installation of PP belt reel:
1) First, unscrew the handwheel and remove the outer banding disk.
2) Next, load the PP tape roll, the tape ring should be loaded according to the rotational direction marked on the tape disk, and the bracing claws hold up the tape ring.
3) Load the outer belt disk, please note that when loading the outer belt disk, the slot on the disk should be aligned with the pin on the shaft.
4)Tighten the handwheel
Control Panel-----
The control panel is easy to operate and has a low failure rate. It is equipped with buttons with different functions:
Feed button
Power indicator
Bundling method
Momentary button
Emergency stop switch
Reel Large PP strapping reel-----
Enlarged, thickened, stable and non-deformed, easy to replace,
Packing machine delivery:
1. The PP belt automatic packing machine is fixed on a pallet.
2.PP belt automatic packaging will be packaged in a carton and fixed.
3.PP belt automatic packaging will be delivered by sea.
4.PP belt automatic baler will have a logistics tracking number after delivery.
.
FAQ:
Q: Can we place a small order?
A: Yes, we can accept small orders
Q: How long is the delivery time?
A: We will complete the delivery within 3- 10 days after you place the order
Q: Can I get some samples to test before placing an order?
A: Yes, if you are willing to pay the courier fee, we can provide some samples for free for your inspection.
Q: Can you accept us to visit your factory?
A: Welcome to visit our company
Q: Can you make other sizes and packages for this product?
A: Yes, we can produce other sizes according to your requirements, usually our quotation includes ordinary packaging.
If you need your own package, you'd better let us know your requirements in advance so as to get an accurate quotation
